Advanced Technology Vibration Shaker Table For Laboratory Testing With Life-Long Maintain

Name: Advanced Technology Vibration Shaker Table For Laboratory Testing With LifeLong Maintain
Brand: LABTONE
Price: 1 USD

China Advanced Technology Vibration Shaker Table For Laboratory Testing With Life-Long Maintain wholesale

Brand Name : LABTONE

Model Number : EV430

Certification : CE / ISO

Place of Origin : Dongguang, China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 15 Sets / Month

Delivery Time : 45 Working Days

Packaging Details : Plywood Case with Vacuum Packing

Product Name : Vibration Shaker Table

Max. Velocity : 250 cm/s

Maximum Displacement : 100mmp-p

Frequency Range : 2-2500 Hz

Payload : 500 kg

Power Amplifier : 3-phase AC 380V 50Hz

Rated Force : 32 KN

Contact Now

Advanced Technology Vibration Shaker Table For Laboratory Testing With Life-Long Maintain

Main Features

Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability
Load center airbag has high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation
High efficiency D class power switching, 3-sigma peak current, provide finest power consumption and minimize harmonic distortion
Quick self-diagnosis with safety interlock, high safety reliability
Airbag shock isolation device for vibration platform without the need of additional foundation, perfect reproduction of vibrational wave and reduce vibration transmittance
Provide horizontal and vertical expansion platform for different application
Simple controller operation

Specifications

Model	EV340	EV350	EV420	EV430	EV440
Vibration Generator	VG4000/76	VG5000/76	VG2000/100	VG3000/100	VG4000/100
Frequency(Hz)	2-2500	2-2500	2-3000	2-2500	2-2500
Max Exiting Force(kg.f)	4000	5000	2000	3200	4000
Max. Displacement (mmp-p)	76	76	100	100	100
Max. Acceleration(g)	80	100	90	71	66
Max. Velocity(cm/s)	200	200	200	250	250
Payload(kg)	1000	1000	500	500	800
Armature Mass(kg)	50	50	23	45	60
Armature Diameter(mm)	φ440	φ440	φ320	φ400	φ445
Cooling Method	Forced Air Cooling
Vibration Generator Weight(kg)	3500	3800	2000	3200	4200
Vibration Generator Dimension LWH(MM)	110013001520	110013001520	85010001100	110013001440	110013001520
Power Amplifier	Amp55k	Amp70k	Amp35k	Amp40k	Amp60k
Power Amplifier Weight(kg)	800	900	550	600	800
Power Amplifier Dimension LWH(MM)	8005501920	8005501920	8005501520	8005501920	8005501920
Utility Requirements	3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW)	80	90	45	64	85

Standards: MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.

Application: Automotive, Electronics, Aerospace, Vessel, Telecommunication, Photoelectronics, Instrument etc.

Service

Pre-Sales Service

1)Technical consultation: test method, laboratory planning and suggestion.

2)Equipment selection: selection scheme, FAQ.

3)Product testing scheme.

4)Customer communication and progress report.

After-Sales Service

1)Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.

2)Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.

3)Technical support: special paid services are provided according to customer’s needs.

Details

Advanced Technology Vibration Shaker Table For Laboratory Testing With Life-Long Maintain

Product Tags:

vibration testing equipment

dynamic testing equipment

Advanced Technology Vibration Shaker Table For Laboratory Testing With Life-Long Maintain Images
